La Spaziale COMPACT - Water Mains Installation Diagram

INSTRUCTIONMANUALFORTHEINSTALLER

      

      

 








Watertap(previouslyinstalledbythecustomer)
Motorpump(providedwiththemachine–when
notbuiltin)
Watersoftener(optional)
Drainsiphon(previouslyinstalledbythecustomer)
High-pressurehoses(supplied)
Waterdrainpipe(providedwiththemachine)
1
5
6
4 2 3
003

 

 
 





Whenthereisnowatersoftener,itisnecessarytoapplyalterontheinletpipeofthemotorpump,in
ordertopreventimpuritiesfromdamagingthemotorpumportheapplianceitself.




Beforeconnectingthehosecomingfromthemotorpumporfromthewater-softener,incaseofappliances
withbuilt-inpumps,placeitinabucketandturnonthewatertap(1-Pict3)foracoupleofminutesinorder
toeliminatepossibleresiduesfromthenewhosesandinanycase,untilthewaterowsclear.
