INSTRUCTIONMANUALFORTHEINSTALLER


Pressthecupwarmeroperatingbutton(24)andcheckitsoperatingstatusthroughthelightingupofthe
LED(23)onthecontrolpanel.Toswitchitoff,pressthesamebutton.

Holddownthefreeowdeliverybutton(29)ofthersttouchpadontheright(1stGROUP)forabout
,untilthesymbol
startstoash(thedosesymbolswillremainlit)andthesymbolsofallthe
othertouchpadsswitchoff.
Thesymbolonthetimedwaterdeliverybuttonwillstarttoash.
Pressthebuttonfortimedhotwaterdelivery(42);thesymbolwillstopashingandstaylittoindicatethat
programmingisinprogress.
Whenthedosehasreachedtherequiredamount,pressthebutton(42)againtostop.


 
This model communicates any anomalies through the relevant symbols on the control panel and
touchpads.
1. SYMBOLCORRESPONDINGTOTHECOFFEEDOSEBUTTONONDELIVERYMODE,FLASHING
AFTER5-6SECONDS:
• Coffeegroundtoonely.
• Missingreadingofthepulsessentbytheowmetertothedeliverygroup.
2. ALL DOSE SYMBOLS ON ALL TOUCHPADS FLASHING AND TEMPERATURE SYMBOLS
SWITCHEDOFF:
• Theautomaticrellsystemfortheboilerhasbeenoperatingforlongerthan(totalblockof
allmachineoperations).Torestorenormaloperation,switchthemachineoffusingthemainswitch.
Iftheproblemoccursagain,checktheautomaticrellsystemfortheboiler.
3. “125°C”SYMBOLLITANDALLOTHERSYMBOLSSWITCHEDOFF:
• Whenthetemperaturedetectedbytheprobeisabove.
 Checkthetemperatureprobeconnectionstothecontrolboardorreplacetheprobe.Alternatively,
checktheoperationofthestaticrelays.
4. “105°C”SYMBOLLITANDALLOTHERSYMBOLSSWITCHEDOFF:
• When,afterswitchingon,thetemperaturedetectedbytheprobeislessthan.
 Checkthetemperatureprobeconnectionstothecontrolboardorreplacetheprobe.Alternatively,
checkthesafetythermostat.
5. ALLTEMPERATURESYMBOLSFLASHINGANDALLTOUCHPADSYMBOLSSWITCHEDOFF:
• Thereisatemperatureprobeshortcircuitorinterruption.
 Checkthetemperatureprobeconnectionstothecontrolboardorreplacetheprobe.





