La Spaziale COMPACT - Elettrik Model

INSTRUCTIONMANUALFORTHEINSTALLER

 
              





Electricconnectioncontrollight.
Controllightindicatingheatregulationstatus(whethertheheatingelementsoftheboilerareenabled).
Controllightfortheoperatingstatusoftheboilerheatingelements.
Controllightforautomaticboilerrell.
Controllightforelectriccupwarmerheatingelements.

SwitchingON/OFFofboilerheatingelements.
SwitchingON/OFFofcupwarmerheatingelements.
• Boilertemperaturesetreading.
• Keepingthisbuttonpressedforabout5-6secondsautomaticallyincreasesthesettemperatureby2°C
andthemessage“UP”isshown,alternatedwiththetemperaturevalue.Tocancelthisstatus,press
thebuttonagainuntilthestandardoperatingtemperatureisshown.


 normaloperation
 accesstotemperatureparametersettings
 normaloperation
 accesstocontrolboardself-diagnostics






CONTROLPANEL
