Chapter 3: Getting Started
Product Service 816-333-8811 or 1-800-522-7658
10
Plus the Following:
Part # Component Description
7387900 User’s Manual
1336400
1342100
1336500
Power Cord – 115V
or
Power Cord – 230V, 60 Hz
or
Power Cord – 230V, 50 Hz
1291000 Plug (230V models only)
7646000 Vacuum Hose
1967600 Hose Clamps (2)
7395801 Chamber Lid
7395800 Lid Gasket
7522800 Drying Chamber with 12 valves
If you did not receive one or more of the components listed for your freeze
dryer, or if any of the components are damaged, contact Labconco
Corporation immediately for further instructions.
Setting Up Your Freeze Dryer
After you verify receipt of the proper components, move your freeze dryer to
the location where you want to install it. Then, follow the steps listed below.
Vacuum Pump Connection
A vacuum pump as described in Chapter 2: Prerequisites is required to
operate your freeze dry system properly. The freeze dryer is equipped with a
3/4" ID, heavy wall, vacuum hose for connecting the collector chamber to the
vacuum pump.
Place the vacuum pump near the benchtop freeze dryer models. For console
models, from the back of the unit, place the vacuum pump on the floor of the
cabinet.
Connect the vacuum pump power cord to the receptacle on the back of the
cabinet labeled “vacuum pump.” If the vacuum pump has an off/on switch,
turn the switch on. The vacuum pump will be controlled by the freeze dryer.
Connect the vacuum pump inlet port to the vacuum tube on the back of the
cabinet with the vacuum hose and clamps provided. If necessary, cut the
hose to proper length to allow for gentle bends without kinks.
Models rated for use on 230V have a reverse IEC connector for attaching the
vacuum pump power cord. A plug is supplied that can be installed on the
vacuum pump power cord if necessary. Make certain that the oil in the
vacuum pump is at the proper level.
