Labconco FreeZone Plus User Manual

Product Service 816-333-8811 or 1-800-522-7658
42
A
A
P
P
P
P
E
E
N
N
D
D
I
I
X
X
A
A
F
F
R
R
E
E
E
E
Z
Z
E
E
D
D
R
R
Y
Y
E
E
R
R
C
C
O
O
M
M
P
P
O
O
N
N
E
E
N
N
T
T
S
S
The following is a list of components that are available for your freeze dryer.
The parts shown are the most common replacement parts. If other parts are
required, contact Product Service.
Models 73860xx and 73870xx
Item Part No. Description
1 7395800 Lid Gasket
2 7395801 Lid
3 7388400 Back Panel Assembly, 115V
7388401 Back Panel Assembly, 230V
4 7953800 Motor Fan, 115V
7953801 Motor Fan, 230V
5 7591800 Compressor, 115V, 60 Hz Lo Stage
7591801 Compressor, 230V, 50 Hz Lo Stage
7591802 Compressor, 230V, 60 Hz Lo Stage
7591800 Compressor, 115V, 60 Hz Hi Stage
7591801 Compressor, 230V, 50 Hz Hi Stage
7591802 Compressor, 230V, 60 Hz Hi Stage
6 1302300 Switch
7 7426000 Control Panel Label
8 7445500 Printed Circuit Board
9 7728000 Drain Plug
10 1643600 O-Ring
11 7645900 Drain Hose
12 7646000 Vacuum Hose (Not Shown)
13 1336400 Power Cord, 115V (Not Shown)
1342100 Power Cord, 230V, 60 Hz (Not Shown)
1336500 Power Cord, 230V, 50 Hz (Not Shown)
14 7445400 Vacuum Sensor
15 7515300 Temperature Sensor, Collector (Not Shown)
16 7389400 Wire Harness, 115V (Not Shown)
7389401 Wire Harness, 230V (Not Shown)
17 7432700 Vacuum Control/Bleed Valve
18 7429700 Moisture Sensor
19 7389700 Wire Harness, Control, 115V & 230V (Not Shown)
