Labconco Protector Premier 10040 Series User Manual

Chapter 7: Modifying Your Protector Premier
Product Service 1-800-522-7658
33
Original instructions
Configure Your Adjustable Height Ceiling Enclosure Kit Catalog Number
Use this key to configure the seven digit catalog number to order your 3-Sided Adjustable Height
Ceiling Enclosure Kit. For example, 9425501 is a 3-Sided Ceiling Enclosure Kit for a 5' Protector
Premier Hood with a height range of 14-19".
9
4
2
5
___
___
___
STEP 1. Select the nominal
width of your fume hood. This
number is the fifth digit of your
catalog number.
3 = 3' (XL Benchtop only)
4 = 4'
5 = 5'
6 = 6'
7 = 7' (XL Benchtop only)
8 = 8'
STEP 2. Select the depth
based on the model chosen.
Choose 0 for Premier and 1
for XStream. Choose 1 for
PVC. Choose 0, 1 or 2 for
the correct depth of the XL
Benchtop model. Choose 0
or 1 for the correct depth of
Stainless Steel. This is the
sixth digit of your catalog
number.
STEP 3. Choose the correct
height range that matches
the number. This height
range should match the
height between the top of the
hood and the building
ceiling. This is the seventh
digit of your catalog number.
Note: The previous generation listed as 9414-W-D-H is presented below to aid
product service.
9
4
1
4
W
D
H
No.
Height Range
0
11-14"
1
14-18.6"
2
18.6-24.4"
No.
Ext. Depth
Model
0
31.7"
Premier,
XL Benchtop,
Stainless Steel
1
37.7"
XStream,
XL Benchtop,
XL Floor-Mounted,
Stainless Steel,
PVC
2
43.7"
XL Benchtop,
XL Floor-Mounted
