APPENDIX A
PROTECTOR PREMIER COMPONENTS
Illustration A-1 indicate the location of the following service parts:
Item
Quantity
Part No.
Description
1A
1
9823700
Valve, Labconco (Water) 1/4" Compression Fitting
1B
1
9823701
Valve, Labconco (Water) 3/8" Compression Fitting
1C
1
9817000
Valve, Labconco 1/4" Compression Fitting (AIR, GAS, VAC, NIT, etc.)
1D
1
9817001
Valve, Labconco 3/8" Compression Fitting (AIR, GAS, VAC, NIT, etc.)
1E
1
9823702
Valve, Labconco Deionized 1/4" Compression Fitting
1F
1
9823703
Valve, Labconco Deionized 3/8" Compression Fitting
1G
1
9818000
Nut, Valve Mounting (Labconco)
2A
1
9826800
WaterSaver Valve/Gooseneck – GRN
2B
1
9826801
WaterSaver Valve/Connector (VAC) – YEL
2C
1
9826802
WaterSaver Valve/Connector (AIR) – ORG
2D
1
9826803
WaterSaver Valve/Connector (GAS) – BLU
2E
1
9826805
WaterSaver Valve/Connector (HOT WATER) – RED
2F
1
9826806
WaterSaver Valve/Connector (CW) – GRN
2G
1
9826807
WaterSaver Valve/Connector (STEAM) – BLK
2H
1
9826808
WaterSaver Valve/Connector (NITROGEN) – BRN
2I
1
9826809
WaterSaver Valve/Connector (OXYGEN) – LIGHT GREEN
2J
1
9826810
Swivel Gooseneck only – GRN
2K
1
9826812
Swivel Gooseneck only – WHITE
3
1
9818700 thru 08
Knobs (GRAY, GRN, BLU, ORG, YEL, RED, WHT, BLK, BRN)
4A
1
9818800
Hose Barb, GRAY (NEUTRAL OR ARGON) – NOT SHOWN
4B
1
9818801
Hose Barb, GREEN (COLD WATER) – NOT SHOWN
4C
1
9818802
Hose Barb, BLUE (GAS) – NOT SHOWN
4D
1
9818803
Hose Barb, ORANGE (AIR) – NOT SHOWN
4E
1
9818804
Hose Barb, YELLOW (VACUUM) – NOT SHOWN
4F
1
9818805
Hose Barb, RED (HOT WATER) – NOT SHOWN
4G
1
9818806
Hose Barb, WHITE (DEIONIZED WATER) – NOT SHOWN
4H
1
9818807
Hose Barb, BLACK (NEUTRAL OR STEAM) – NOT SHOWN
4I
1
9818808
Hose Barb, BROWN (NITROGEN) – NOT SHOWN
4J
1
9819000
Nut, Hose Barb – NOT SHOWN
5
1
9825500
Label, Knob (contains all the labels)
6
1
9818900
Lens, Knob
7A
1
9947100, 01, 02
115V Duplex Receptacle (GRAY) Right, Left 4' - 6', Left 8' w/ wires
7B
1
9818200
Cover Plate 115V Duplex
7C
1
9947103, 04, 05
115V GFCI Duplex Receptacle (GRAY) Right 4' - 6', Left 8' w/ wires
7D
1
9818100
Cover Plate, 115V GFCI
7E
1
9818300
Cover Plate, Blank
8A
1
1297503
LED, Direct Wired T8 x 3' – newest models use on 4' & 8' Hoods –
12 watts each
8B
1
1297504
LED, Direct Wired T8 x 4' – newest models use on 5' & 6' Hoods –
22 watts each
