Appendix A: Protector Premier Components
Product Service 1-800-522-7658
41
Original instructions
Item
Quantity
Part No.
Description
8C
1
9945300
LED Light Fixture, 36" – use on 4' Hoods
8D
1
9945301
LED Light Fixture, 48" – use on 5', 6' Hoods
8E
1
9945302
LED Light Fixture, 36" Combo – use on 8' Hoods
10A
1
1302301
Switch, Rocker
10B
1
1327500
Switch, Plug (Fills cutout when switch is not used)
11
1
9818400
Access Cover
12A
1
9409800
Side Panel, 24" internal deep hoods
12B
4
1885308
Screw, Machine #10-24 x .50 Phillips
13A
1
9436501
Eco-Foil 4'
13B
1
9436502
Eco-Foil 5'
13C
1
9436503
Eco-Foil 6'
13D
1
9436505
Eco-Foil 8'
13E
1
9436521
PVC Eco-Foil, 4'
13F
1
9436522
PVC Eco-Foil, 5'
13G
1
9436523
PVC Eco-Foil, 6'
13H
1
9436525
PVC Eco-Foil, 8'
14
2
1850000
Pulley, Front, 2" Dia. Nylon
15A
2
4949902
Cable, Sash 130" – NOT SHOWN
15B
2
9414010
Cable Replacement Kit 24"
15C
1
9545800
Weight Support Bracket Kit
16
2
9709300
Plastic Pulley, (Rear 2")
17
2
9713300
Bumper, Rubber (lower sash bumper) – NOT SHOWN
18
4
1934100
Bronze Bearing, Flanged Rear – NOT SHOWN
19
4
1920100
Clamp, Cable Replacement – NOT SHOWN
20
2
9935800
Threaded Connector (to attach weight to cable) – NOT SHOWN
21
1
9946300 or 01
Wiring Harness, Main
22
1
9409601, 02, 03, 05
Front Panel, 4', 5', 6', 8'
23
1
1859900
Belt-V 3L380
24A
1
1209400
Motor, 1/3 HP 4' 115V/230V (all 60 Hz)
24B
1
1209500
Motor, 1/2 HP 5' & 6' 115V/230V, 60 Hz
24C
1
1206600
Motor, 1/3 HP EP 4' 115V/230V, 60 Hz
24D
1
1208200
Motor, 1/2 HP EP 5' & 6' 115V/230V, 60 Hz
24E
1
1202400
Motor, 1/2 HP 4', 5' & 6' 230V (all 50 Hz)
25
1
4862900
Wheel, Blower
26
1
4863400
Shaft, Blower
27
2
1863000
Bearing, Pillow Block
