Chapter 4: Using Your Washer
Product Service 1-800-522-7658
24
Two sizes of spindles are provided with the washer: thirty-six .25" (6.35 mm) OD
and ten .125" (3.18mm ) OD spindles. The optional Forty-Eight Pin Insert
(Labconco P/N 4591601) may be positioned directly over spindles or spindles can
be removed with a screw driver and replaced with the plugs included with the
washer.
Optional top racks are available for the FlaskScrubber to expand the washer’s
capacity to accommodate many types of glassware. An Upper Spindle Rack
(Labconco P/N 4595600) is available with 30 spindles.
Loading Glassware into the FlaskScrubber
Glassware Holders are supplied with each FlaskScrubber. These holders enable
you to position glassware onto the FlaskScrubber spindles.
To use a Glassware Holder:
1. Press the glassware into the holder; the clamps should spring out and grip the
glassware.
Note: It is normal for the clamps to deform if large glassware is inserted into
the Holder and the washer is operated at high temperature. Do not use with
glassware over 2.5 inches in diameter as damage to holder may occur.
2. The holder may be raised or lowered by squeezing the spring clip on the
bottom of the holder and then sliding the holder up or down.
3. For best results, do not allow the glassware to rest directly on top of the
spindle.
