Chapter 5: Maintaining Your Washer
Product Service 1-800-522-7658 35
Removing the Washer Top, Back, and Side Panels
There may be times when you need to remove the washer top, back, and side
panels to clean, maintain, or repair your washer. Refer to the figure below and
follow the instructions to remove the top, back, and side panels of your washer.
To remove the washer top, back, and side panels:
1. Turn off electrical power to the Glassware Washer.
2. Remove all of the screws from the back panel of the washer and remove the
back panel.
3. Remove the 2 screws at the kick panel.
4. Remove 2 screws at the rear that hold the sides to the top.
5. Remove the two screws from each side of the washer at the front edge.
6. Remove the side panels.
7. Remove the 2 screws that hold the top.
8. Remove the top.
