Labgear LCOM1 - Technical Specifications

14
SECTION ITEM DESCRIPTION
Processor
CPU Montage M88CS8051B-T00D
Flash Memory 8MB
DDR2 1GB
DVB-S/S2
Tuner
Input Frequency: 950 ~ 2150MHz
Input level: -80 ~ -20dBm
Input impedance 75 Q
DVB-T/T2
Tuner
VHF: 174 ~ 230MHz,
UHF: 470 ~ 862MHz
RF input Signal Level: -78 ~ -5dBm
Channel
Decoding
Demodulation QPSK, BPSK, 16PSK
FEC mode
DVB-S 1/2, 2/3, 3/4, 5/6, 7/8
DVBS2X: 1/23/5,2/3,3/4, 4/5, 5/6, 8/9, 9/10(QPSK)3/5 ,2/3, 3
4, 5/6, 8/9, 9/10 (8PSK)
Symbol Rate DVB-S: 2.0 ~ 45 MS/s
Demodulation QPSK, 8PSK, DVB-S2:1030Mb/s(QPSK),10-31Mb/s (8PSK)
Demultiplexer
Standard ISO/IEC 13818-1
Input Max. Bit Stream Rate 100Mbps (Serial) / 12. 5Mbps (Parallel)
Video
Decoding
Standard ISO/IEC 13818-2, MPEG-2 MP@ML, MPEG-4, AVC (MP L4.1)
Aspect Ratio 4:3, 16:9
Video Format PAL-B / NTSC-M / PAL-N / PAL-M
Video Resolution 1080p, 1080i, 720p, 480p / 576p, 480i / 576i SD, compatible
Audio
Decoding
Standard ISO/IEC 13818-3
Decoding MPEG-1 Layer | and II, MPEG-2, MPEG-4 AAC
Output Mode LPCM, RAW
Sampling Frequency 32, 44.1, 48KHz
Volume Level 24 Levels
AV Output
Video de emphasis CCIR REC.405-1, 625LINES
Video bandwidth 5.5MHz
Video output impedance 75Ω
Video output level 1.0Vp-p
Audio output Stereo
Audio output frequency 20Hz ~ 20KHz
Audio output impedance Low
Audio output level A 1.0Vrms ± 2dB into 10K.
Panel Interface
• 1x Mini AV • 1x HDMI • 1x LNB In • 1x ANT In • 2x USB 2.0 Port
• 1x Ethernet • 1x DC-IN • 1x Coaxial
Power Power input Specification 12V/1A DC In Max. 8W
Specifications
