Over voltage protection
The radio has a high voltage input detection system, to warn you if an over voltage situation occurs.
Example: If the power supply voltage exceeds 17volts DC, the cannel display (LCD backlight)
will flash in 3 different colors when the unit is turned on.
If the over voltage warning appears, you must switch your radio off and disconnect it from the
power source, before location the cause of the trouble.
Radio stays ON when the ignition is switched OFF
Connect the radio’s negative (black) lead to the vehicle chassis, or directly to the batteries nega-
tive terminal. Connect the radio’s positive (red) lead via the 2 A fuse to the attery’s positive termi-
nal. Alternatively, the positive lead could be connected at the fuse box at a point that has 13.8
volts continuously available(preferably the battery side of the ignition switch) via the 2A fuse.
Radio turns OFF with the ignition switch
Connect the radio’s negative (black) lead to the vehicle’s chassis, or directly to the atteries nega-
tive terminal. The radio’s positive(red) lead should connect to an accessory point in the vehicle’s
fuse box via the 2 Amp fuse.
Antenna information
The antenna (not supplied) is of critical importance, to maximize your output power and
receiver sensitivity.
A poor quality antenna or one not designed for the specific frequency band you are
using will give poor performance. You should purchase an antenna designed for the
27MHz frequency band.
Antenna installation
Connect the antenna to the rear antenna socket using a PL-259 coaxial connector.
To obtain maximum performance from the radio, select a high quality antenna and mount it
in a good location. Do not press the PTT before installing the antenna.
Optional accessories
If required you may install an external (8ohm,max 5w power) speaker fitted with 3.5mm mono
plug (not supplied) There is a jack located on the rear of the radio.
