Specifications
General
Transmitter Crystal Controlled PLL Synthesizer
Receiver Double Conversion and Superheterodyne System
Voltage Operation 13.8V dc
If you more supply until 17V, Automatic detection of over voltage
So blinking of LCD display backlight at rotation three colors.
Channel Step 10kHz
Dimension (H x W x D) microphone: 95 x 58 x 25 mm
main unit: 29 x 108 x 136 mm
3.5mm External SPK Jack Mono Type
Antenna connector SO-239 (50 Ohms socket for PL-259 plugs)
Condensor Microphone Corresponds to 6 pin standard wiring except 4 pin
Transmitter
RF Output Power FM: 4W - AM: 4W (AM: 1W in Germany)
Frequency Range See table pag. 22
Frequency Error < ±600Hz
Microphone Sensitivity 2.5mV (1250Hz input)
Modulation Capability AM 80% - FM 2.0 kHz
Receiver
Maximum Sensitivity
at 12dB SINAD
AM : -120dBm - FM: -121dBm
Squelch Close sensitivity -126dBm at SQ1 - -47dBm at SQ15
Auto Squelch -120dBm
S/N Ratio 40dB
Distortion <5%
Signal meter sensitivity
at maximum
-67dBm at 3 digit
Audio Output Power Minimum 2 W at 8 ohms
Test Condition
Power Source 13.8 V dc
Antenna Impedance 50 Ohm
Audio Load Impedance 8 Ohm
