Lagoon 440 - Washing Machine - Dishwasher - Heating

WASHING MACHINE - DISHWASHER - HEATING
48
LAYOUTS
LAGOON 44O
Diesel fuel heater 4000 watts
Forced air outlet
Heater exhaust outlet
Starting and temperature control
2
4
3
1
6
HEATING
WASHING MACHINE - DISHWASHER
1 - Electrical protection fuses.
2 - Dishwasher (110 V - 220 V).
3 - Water inlet valve for washing machine.
4 - Drain valve for washing machine.
5 - Washing machine (110 V - 220 V).
6 - Drain valve for dishwasher.
7 - Water inlet valve for dishwasher.
7
4
5
The positions are the same for the other layout version.
