ELECTRICAL PANELS
56
ELECTRICITY
LAGOON 44O
1 - Navigation lights.
2 - Mooring lights.
3 - Steaming light.
4 - Deck light.
5 - Interior lighting.
6 - Saloon lighting.
7 - Instrument lighting.
2
1
3
4
5
6
7
8
10
9
11
12 13 14 15 16
17
18
19
20
15 - Port bilge pump.
16 - Miscellaneous 2.
17 - 220 V AC sockets.
18 - 220 V AC battery charger.
19 - 220 V AC water heater.
20 - 220 V AC miscellaneous.
8 - 12 V DC socket.
9 - Water pump.
10 - Starboard bilge pump.
11 - Refrigerator.
12 - Confort (Waste water pump).
13 - Navigation station.
14 - VHF.
AIR CONDITIONING PANEL
