1.2.9 Cooling and mechanical construction
The Genesys
TM
series is cooled by internal fans. At the installation, care must be taken to allow
free airflow into the power supply via the front panel and out of the power supply via the rear
panel. The Genesys
TM
power supplies have a compact and lightweight package, which allows
easy installation and space saving in the application equipment.
1.3 ACCESSORIES
1.3.1 General
Accessories are delivered with the power supply or separately upon ordering. The list below
shows the possible accessories and ordering numbers.
1.3.2 Serial Link Cable
Serial link cable, for linking power supplies by RS485 communication is provided with the power
supply.
Cable description: 0.5m length, shielded, RJ-45 type plugs, 8 contacts (P/N:GEN/RJ-45).
1.3.3 Misc. hardware
∗
DB25 plug (AMP, 745211-2).
∗
Output terminal shield
1.3.4 AC cables
AC cables are not provided with the power supply. If an AC cable is required, it should be ordered
according to following:
For 750W Genesys
TM
power supplies:
Part No. Market Description
NC301
(GEN/U)
USA 13A 125V, unshielded, 2m typical length, with IEC320 connector on one end
and NEMA-5-15P connector on the other end.
NC302
(GEN/E)
Europe 10A 250V, unshielded, 2m typical length, with IEC320 connector on one end
and INT’L 7 standard VII, dual earthing.
NC303
(GEN/O)
General 10A 250V, unshielded, 2m typical length, with IEC320 connector on one end
and unterminated stripped wires on the other end. Use the cable only with
plug approved by the national safety standards of the country of usage.
NC305
(GEN/J)
Japan 13A 125V,unshielded, 2m typical length, with IEC320 connector on one end
and Japan type plug on the other end.
NC306
(GEN/GB
)
UK 10A 250V unshielded, 2m typical length, with IEC320 connector on one end
and UK type plug on the other end.
1.3.5 Serial Port Cables Refer to Section 7.5
CAUTION
Observe all torque guidelines within this manual. Applying more torque may
damage unit or accessories. Such damage is not covered under manufacturers
warranty.
