Lambda Genesys GENH 750W - Isolated Programming & Monitoring Connector

83-507-5002 Rev. A
70
CAUTION
When the Isolated Analog Option is installed, do not apply any signals to the
non-isolated VPGM and IPGM (J1-9 and J1-10) pins. All other J1 features may
be used normally. Refer to Section 4.5 for a description of J1 features.
8.3 ISOLATED PROGRAMMING & MONITORING CONNECTOR
Refer to Table 8-1 for detailed description of the rear panel Isolated Programming & Monitoring
connector. To provide the lowest noise performance, it is recommended to use shielded-twisted
pair wiring.
Refer to Fig.8-1 for description of the Isolated Analog Programming & Monitoring connector.
Isolated programming plug P/N: MC1.5/8-ST-3.81, Phoenix.
Table 8-1: Detailed description of Isolated programming & Monitoring connector
Terminal Signal name Function
Range 0-5/0-
10V
IS510 option
Range 4-
20mA IS420
option
1 SHLD
Shield, connected internally to
chassis of the power supply.
Chassis ground
2 +VPROG_ISO
Output Voltage programming
input
0-5V/0-10V 4-20mA
3 +IPROG_ISO
Output Current programming
input
0-5V/0-10V 4-20mA
4 GND
Ground for programming sig-
nals.
Ground Ground
5 GND
Ground for programming sig-
nals.
Ground Ground
6 +VMON_ISO
Output voltage monitoring out-
put
0-5V/0-10V 4-20mA
7 +IMON_ISO
Output current monitoring out-
put
0-5V/0-10V 4-20mA
8 SHLD
Shield, connected internally to
chassis of the supply.
Chassis ground
1
2
3
4
5
6
7
8
Shield
+VPROG_ISO
+IPROG_ISO
GND_ISO
Shield
+IMON_ISO
+VMON_ISO
GND_ISO
Fig.8-1: Isolated Programming & Monitoring connector
