83-507-5002 Rev. A
63
8 0.5 10.0 8 0 7.60
12.5 1.0 15.0 12.5 0 11.9
20 1.0 24.0 20 0 19.0
30 2.0 36.0 30 0 28.5
40 2.0 44.0 40 0 38.0
60 5.0 66.0 60 0 57.0
80 5.0 88.0 80 0 76.0
100 5.0 110.0 100 0 95.0
150 5.0 165.0 150 0 142
300 5.0 330.0 300 0 285
600 5.0 660.0 600 0 570
7.10.6 Status Control Commands
Refer to Section 7-8 for definition of the registers.
# Command Description
1 STT? Reads the complete power supply status.
Returns ASCII characters representing the following data, separated by commas:
MV<actual (measured) voltage> PC<programmed (set) current>
PV<programmed (set) voltage> SR<status register, 2-digit hex>
MC<actual (measured) current> FR<fault register, 2-digit hex>
Example response: MV(45.201),PV(45), MC(4.3257), PC(10), SR(30), FR(00)
2 FLT? Reads Fault Conditional Re
g
ister. Returns 2-di
g
it hex.
3 FENA Set Fault Enable Re
g
ister usin
g
2-di
g
it hex.
4 FENA? Reads Fault Enable Re
g
ister. Returns 2-di
g
it hex.
5 FEVE? Reads Fault Event Re
g
ister. Returns 2-di
g
it hex. Clears bits of Fault Event Re
g
ister.
6 STAT? Reads Status Conditional Re
g
ister. Returns 2-di
g
it hex.
7 SENA Sets Status Enable Re
g
ister usin
g
2-di
g
it hex.
8 SENA? Reads Status Enable Re
g
ister. Returns 2-di
g
it hex.
9 SEVE? Reads Status Event re
g
ister. Returns 2-di
g
it hex. Clears bits of Status Event re
g
ister.
7.11 STATUS, ERROR AND SRQ REGISTERS
7.11.1 General Description
This Section describes the various status error and SRQ registers structure. The registers can be
read or set via the RS232/RS485 commands. When using the IEEE option, refer to the User’s
Manual for Genesys
TM
Power Supply IEEE Programming Interface.
Refer to Fig. 7-7 for the Status and Error Registers Diagram.
