Lambda Genesys GENH 750W - Page 69

83-507-5002 Rev. A
62
returned.
Retransmit last
message
110x xxxx
Last message
Retransmit last response from a
command. x xxxx is the address of
the supply in binary.
Acknowledge
SRQ
111x xxxx
None
Acknowledge SRQ. If retransmis-
sion of SRQ is enabled, it will re-
main enabled for the next SRQ. X
xxxx is the address of the supply in
binary.
Test if MD Mode
is Installed
Byte 1
1010 1010
Byte 2
xxxx xxxx
0 or 1
Returns a 0 if not installed or a 1 if
installed. A ‘$’ sign followed by a 2
bytes checksum and Carriage Re-
turn is appended to the data. xxxx
xxxx is the address of the supply in
binary.
Supply Initiated
Communications
SRQ 100x xxxx
N/A
SRQ from supply when in MD
Mode. X xxxx is the address of the
supply in binary.
Table 7-4. SINGLE BYTE COMMUNICATIONS
GEN750W models
Table 7-5: Current programming range
Model Minimum
(A)
Maximum
(A)
GEN6
-
100
000.00
100.00
GEN8
-
90
00.00
90.00
GEN12.5
-
60
00.000
60.000
GEN20
-
38
00.000
38.000
GEN30
-
25
00.000
25.000
GEN40
-
19
00.000
19.000
GEN60
-
12.5
00.000
12.500
GEN80
-
9.5
0.000
9.500
GEN100
-
7.5
0.000
7.500
GEN150
-
5
0.000
5.000
GEN300
-
2.5
0.000
2.500
GEN600
-
1.3
0.000
1.300
NOTE:
The power supply can accept values higher 5% than the table values, however it is not
recommended to program the power supply over the rated values.
Table 7-6: OVP programming range Table 7-7: UVL programming range
Model
Rated Output Voltage
(V)
Minimum
(V)
Maximum
(V)
Model
Rated Output Voltage
(V)
Minimum
(V)
Maximum
(V)
6
0.5
7.50
6
0
5.70
