Lamborghini Caloreclima EM 3 ST-E - Dimensions mm; Main Components

- 25 -
ENGLISH
DIMENSIONS mm
MAIN COMPONENTS
Legend
1 Gas pressure switch
2 Operation valve
3 Ignition transformer
4 Boiler connecting flange
5 Control box
6 Components plate
7 Motor
8 Air pressure switch
9 Combustion head
10 Burner body
11 Cover
12 Air gate
13 Fan
14 Safety valve
15 Stabilizing filter
* The dimensions refer to a burner with a 20 mbar gas train fitted.
EM 3 ST-E
EM 6N ST-E
250
280
215
247
320
342
160
195
80
80
-
-
85
135
135
1/2”
1/2”
Model
A
B
C
D
Ø F
Ø H
Ø*
min. max.
min. max.
160
160
M8
M8
E
Ø G
I
90
90
L*
M*
410
410
145
145
60
80
Ø P
