Lance 1130 - 12 VOLT EXTERIOR CIRCUITS

116
BATTERY
8 GA BLACK
8 GA WHITE
BREAKAWAY
SWITCH
LOAD CENTER/
CONVERTER
GROUND BAR
30 AMP
MINI
BREAKER
BA
BLACK
BLUE
WHITE
GREEN
RED
YELLOW
14GA GREEN
14GA WHITE
7-PIN BARGMAN CONNECTOR
8GA BLACK
WIRE BRAKE
12-2 JACKETED
8 GA WHITE
10 GA WHITE
WIRE BRAKE
12-2 JACKETED
WIRE BRAKE
12-2 JACKETED
C/S BRAKES R/S BRAKES
GREEN
14 GA WHITE
RED BLUE YELLOW
TO R/S FRONT SIDE MARKER LIGHT. CONNECT TO FRONT WALL RUNNING LIGHT WIRING
REAR WALL
WIRING
TO R/S REAR SIDE MARKER LIGHT. CONNECT TO REAR WALL RUNNING LIGHT WIRING
+
-
BROWN
GREEN RED BLUE YELLOW
J-BOX
(CHASSIS)
12 VOLT EXTERIOR CIRCUITS
GREEN
