lancer IBD 22 - Installation

3
This unit emits a sound
pressure level below 70 dB
CARBON DIOXIDE (CO
2
) SUPPLY
Min Pressure: 70 PSIG (0.483 MPA)
Max Pressure: 80 PSIG (0.552 MPA)
FITTINGS
Plain/Carb Water Inlet: 3/8 inch barb
Brand Syrup Inlets: 3/8 inch barb
DIMENSIONS
Width: 30.0 inches (762 mm)
Depth: 30.5 inches (775 mm)
Height: 34 inches (864 mm)
WEIGHT
Shipping: 305 lbs (139 kg)
Empty: 275 lbs (125 kg)
Ice Capacity: 250 lbs (114 kg)
Ice Dispensable: 175 lbs (79.5 kg)
ELECTRICAL
115 VAC / 60 Hz / 3.6 Amps
230 VAC / 50-60 Hz / 1.8 Amps
PLAIN WATER SUPPLY
Min Flowing Pressure: 25 PSIG (0.172 MPA)
Max Flowing Pressure: 50 PSIG (0.345 MPA)
CARBONATED WATER SUPPLY
Min Flowing Pressure: 25 PSI (0.172 MPA)
Max Static Pressure: 50 PSI (0.345 MPA)
IBD 4500 - 30”
This unit emits a sound
pressure level below 70 dB
CARBON DIOXIDE (CO
2
) SUPPLY
Min Pressure: 70 PSIG (0.483 MPA)
Max Pressure: 80 PSIG (0.552 MPA)
FITTINGS
Plain/Carb Water Inlet: 3/8 inch barb
Brand Syrup Inlets: 3/8 inch barb
DIMENSIONS
Width: 44.0 inches (1117.6 mm)
Depth: 30.5 inches (775 mm)
Height: 34 inches (864 mm)
WEIGHT
Shipping: 460 lbs (208.7 kg)
Empty: 400 lbs (181.4 kg)
Ice Capacity: 360 lbs (163.29 kg)
Ice Dispensable: 300 lbs (136.1 kg)
ELECTRICAL
115 VAC / 60 Hz / 6.0 Amps
PLAIN WATER SUPPLY
Min Flowing Pressure: 25 PSIG (0.172 MPA)
Max Flowing Pressure: 50 PSIG (0.345 MPA)
CARBONATED WATER SUPPLY
Min Flowing Pressure: 25 PSI (0.172 MPA)
Max Static Pressure: 50 PSI (0.345 MPA)
IBD 4500 - 44”
READ THIS MANUAL
This manual was developed by the Lancer Corporation as a reference for the owner/operator and installer of this dispenser. Please
read this guide before installation and operation of this dispenser. If service is required please call your Lancer Service Agent or Lancer
Customer Service. Always have your model and serial number available when you call.
Your Service Agent:
Service Agent Telephone Number:
Serial Number:
Model Numer:
INSTALLATION
Unpack the Dispenser
1. Set shipping carton upright on the oor then cut package
banding straps and remove.
2. Open top of carton and remove interior packaging.
3. Lift carton up and o󰀨 of the unit.
4. Remove plywood shipping base from unit by moving unit so
that one side is o󰀨 the counter top or table allowing access
to screws on the bottom of the plywood shipping base.
DO NOT LAY UNIT ON ITS SIDE OR BACK
! ATTENTION
If unit is to be transported, it is advisable to leave the
unit secured to the plywood shipping base.
NOTE
5. Remove accessory kit and loose parts from ice compartment.
Inspect unit for concealed damage. If evident, notify
 deliveringcarrierandleaclaimagainstthesame.
NOTE
6. If leg kit has been provided, assemble legs by tilting unit.
