6.2 FINAL ASSEMBLY, POST-MIX IBD AND ICE DISPENSER (CONTINUED)
25
Item Part No. Description
R 1 05-1311/01 Wheel Shroud, IBD44
R 2 82-3650 Dispenser, Wheel Assy, Right Side, IBD44
R 3 23-1373 Agitator Assy, HEX, IBD
R 4 10-0762 Pin, Agitator, HEX, IBD
5 03-0368 Retainer, RUE-14-S
R 6 82-3556 Dispenser Wheel Assy, Left Side, HEX, IBD
7 05-1392 Lid, One Piece, 44 Inch IBD
8 82-1980/02 Merchandiser Assy, 44 Inch IBD
9 10-0363/01 Screw, Thumb, IBD
10 12-0128 Lamp, 36 Inch, 30W, CW, 25/R/15
11 23-1038/01 Drain Spider, IBD
12 30-7343/01 Splash Plate, IBD44 (Units manufactured before December 2003)
- 30-8635 Splash Plate, IBD44 (Units manufactured after December 2003)
13 03-0300 Clip, Wire, Adhesive, IBD
14 03-0049 Clip, Cord
15 02-0005 O-Ring, 2-010
16 30-6680 Reector, Merchandiser, Light, IBD44
17 04-0504 Screw, 8 - 18 x 0.375, PHDP
18 04-1089 Screw, 10 - 32 x 1.000, RH, PH/SL
19 82-1871 Drip Tray Assy, IBD44 (Units manufactured before December 2003)
- 82-3187 Drip Tray Assy, IBD44 (Units manufactured after December 2003)
20 04-0559 Cap, Protective, Vinyl, VC-375-8
21 04-0529 Screw, 8 - 32 x 0.750, PH
22 10-0364 Spacer, Drip Tray Lock, IBD
23 30-6145 Lock, Drip Tray, IBD
24 06-1580 Label, Patent
R in margin indicates change or revision
