lancer IBD44 Series - Specifications

IBD - 25” SPECIFICATIONS
DIMENSIONS
Width: 44 in (1118 mm)
Depth: 30.5 in (774.7 mm)
Height: 34 in (863.6 mm)
SPACE REQUIRED
Left Side: 6 in (152.4 mm)
Right side: 6 in (152.4 mm)
ELECTRICAL
115V/60Hz/6 amps
WEIGHT
Shipping: 460 lbs (129.3 kg)
Empty: 400 lbs (113.4 kg)
ICE
Capacity: 360 lbs (95.2 kg)
Dispensable: 300 lbs (77.1 kg)
FITTINGS
Soda water inlet: 3/8” barb
Brand syrup inlets: 3/8” barb
PLAIN WATER SUPPLY
Min owing pressure:
25 PSI (0.172 MPA)
Max owing pressure:
50 PSI (0.345 MPA)
CARBON DIOXIDE (CO2)
Min pressure:
60 PSIG (0.413 MPA)
Max pressure:
80 PSIG (0.552 MPA)
4
