5.2 Connector wiring
5.2.1 Ethernet interface 10/100/1000Base-TX
8-pin RJ45 sockets (ISO 8877, EN 60603-7)
5.3 CE-declarations of conformity
LANCOM Systems herewith declares that the devices of the type described in
this documentation are in agreement with the basic requirements and other
relevant regulations of the 1995/5/EC directive.
The CE declarations of conformity for your device can be found on the relevant
product page on the LANCOM Web site (www.lancom.eu
).
Connector Pin Fast
Ethernet
Gigabit
Ethernet
1T+BI_DA+*
2T-BI_DA-
3R+BI_DB+
4BI_DC+
5BI_DC-
6R-BI_DB-
7BI_DD+
8BI_DD-
