Lanner NCA-4020 - System Specifications

14
System Specifications
Form Factor
1U 19“ Rackmount
Platform
Processor Options
Intel® Xeon® D2100 8/12/16 Cores
CPU Socket
1x FCPGA
Chipset
N/A
Security Acceleration
Intel® QuickAssist Technology
BIOS
AMI SPI Flash BIOS
System Memory
Technology
DDR4 2666 MHz REG DIMM
Max. Capacity
128GB
Socket
4x 288pin DIMM
Networking
Ethernet Ports (By SKU)
10x GbE RJ45 with 8x Port PoE+ and 4x SFP+
or
10x GbE RJ45 with 4x Port PoE+ and 4x SFP+
Bypass
N/A
NIC Module Slot
N/A
LOM
IO Interface
1x RJ45
OPMA slot
IPMI Chip Onboard
I/O Interface
Reset Button
1
LED
Power/Status/Storage
Power Button
1x ATX Power Switch
Console
1x RJ45
USB
2x USB 2.0
LCD Module
N/A
Display
1x Internal Pin Header
Power input
AC /DC power inlet on PSU
Storage
HDD/SSD Support
2x 2.5
”
Internal Bays
Onboard Slots
2x M.2 (w/ LTE support)
Expansion
PCIe
1x PCI-E*8 FH/HL (Optional)
mini-PCIe
1x Mini-PCIe (PCIe*1/USB2.0)
SIM card Slot
3x SIM cover
Miscellaneous
Watchdog
Yes
Internal RTC with Li Battery
Yes
TPM
Yes (Optional)
Cooling
Processor
Passive CPU heat sink
System
3x individual hot-swappable cooling fans
with smart fan
Environmental Parameters
Temperature
0~40ºC Operating
-40~70ºC Non-Operating
Humidity (RH)
5~90% Operating
5~ 95% Non-Operating
System Dimensions
(WxDxH)
438mm x 470mm x 44mm
Weight
7.9kg
Package Dimensions
(WxDxH)
732mm x 582mm x215mm
Weight 13.6kg
Power
Type/Watts
600W 1+1 Redundant PSU
Input
AC 100~240V @47~63 Hz
PoE Power Output
SKU A/B:
25.5W per port, total power budget 204W
SKU C/D:
25.5W per port, total power budget 102W
Approvals and Compliance CE/FCC Class A, UL
