Hardware Installation
Flame-Freezer Heat Sink
The heat dissipating effect of a heat sink mounted directly at the place
where the heat is produced, such as that of a northbridge, is usually lim-
ited. To overcome this problem, the system board uses the heat pipe
technology which is an extremely high thermal conductor that can dissipate
heat effectively. The Flame-Freezer heat sink when installed at the rear of
the chassis provides additional cooling to the entire system.
1. The right photo shows the heat
pipe assembly on the system
board.
Heat pipe
assembly
