Installation
2 - 3
1. Connect the MPS Centronics connector directly to your printerÕs connector.
2a. For MPS1-T and MPS100 models, connect a twisted pair Ethernet cable to the
MPS RJ45 connector.
2b. For MPS1-2 models, connect a thin coaxial Ethernet cable to the MPS BNC
connector.
3. Attach one end of the power cable to the MPS; plug the other end into an
electrical outlet. Power will come on automatically.
NOTE:
The LINK LED indicates a good network connection. The ACT LED gives
information about what the MPS is doing; for example, when code is being
downloaded as the unit boots, the LED will blink green quickly.
Allow 45 seconds for the unit to fully boot. The LINK LED will be lit if there is a
valid connection to the network, and the ACT LED should blink.
4. Print a Test page by pressing the Test/Reset button.
NOTE:
If the Test page does not print, refer to Appendix B, Troubleshooting.
5. Install EZWebCon on your 32-bit Windows PC to conÞgure your Server. The
EZWebCon software is located on the CD-ROM. See EZWebCon ConÞguration on
page 3-2 for more information.
