Lantronix UDS1100 User Manual

3: Getting Started
Type Non-configurable field. Displays the device type as UDS1100.
ID Non-configurable field. Displays the UDS1100’s ID embedded
within the box.
Hardware Address Non-configurable field. Displays the UDS1100’s hardware (or
MAC) address.
Firmware Version Non-configurable field. Displays the firmware currently
installed on the UDS1100.
Extended Firmware
Version
Non-configurable field. Displays the full version nomenclature
of the firmware.
Online Status Non-configurable field. Displays the UDS1100’s status as
online, offline, unreachable (the UDS1100 is on a different
subnet), or busy (the UDS1100 is currently performing a task).
IP Address Non-configurable field. Displays the UDS1100’s current IP
address. To change the IP address, see Assigning an IP
Address on page 18.
IP Address was Obtained Non-configurable field. Indicates whether the current IP
address on the UDS1100 was set manually or assigned by
DHCP.
Subnet Mask Non-configurable field. Displays the UDS1100’s current
subnet mask. To change the subnet mask, see Assigning an
IP Address on page 18.
Gateway Non-configurable field. Displays the UDS1100’s current
gateway. To change the gateway, see Assigning an IP
Address on page 18.
Number of COB partitions
supported
Non-configurable field. Displays the number of COB partitions
supported.
Number of Ports Non-configurable field. Displays the number of ports on the
UDS1100.
TCP Keepalive Non-configurable field. Displays the UDS1100’s TCP
keepalive value. The value is in the range 1-65s, and the
default setting is 45.
Telnet Enabled Non-configurable field. Permits Telnet sessions.
Telnet Port Non-configurable field. Displays the UDS1100’s port for telnet
sessions.
Web Enabled Non-configurable field. Permits configuration through Web-
Manager.
Web Port Non-configurable field. Displays the UDS1100’s port for Web-
Manager configuration.
Maximum Baud Rate
Supported
Non-configurable field. Displays the UDS1100’s maximum
baud rate.
Note: The UDS1100 may not currently be running at this rate.
Firmware Upgradeable
Non-configurable field. Displays True, indicating the
UDS1100’s firmware is upgradeable as newer version
become available.
UDS1100 User Guide 20

Lantronix UDS1100 Specifications

General

Isolation	1.5 kV
Certification	UL, CSA, FCC, CE, TUV, CTick, VCC, UL 864 RoHS
Serial interface type	RS-232/422/485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	100 - 240 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
