Lantronix UDS1100 User Manual

Contents
ARP and Telnet_________________________________________________ 79
C: Binary to Hexadecimal Conversions 80
Converting Binary to Hexadecimal _____________________________________ 80
Conversion Table _______________________________________________ 80
Scientific Calculator______________________________________________ 81
D: Warranty 82
E: Compliance and Disclaimer 83
Index 85
Figures
Figure 2-1. Serial Tunneling Example _____________________________________ 11
Figure 2-2. Direct TCP/IP or Redirector Configuration ________________________ 11
Figure 2-3. Sample Hardware Address ____________________________________ 13
Figure 3-1. UDS1100-POE Version Connected to Serial Device and Network ______ 15
Figure 3-2. Standard UDS1100 Connected to Serial Device and Network _________ 16
Figure 4-1. Web-Manager Login Window __________________________________ 24
Figure 4-2. Lantronix Web-Manager ______________________________________ 24
Figure 4-3. Network Settings ____________________________________________ 25
Figure 4-4. Server Settings _____________________________________________ 27
Figure 4-5. Hostlist Settings ____________________________________________ 29
Figure 4-6. Channel Serial Settings_______________________________________ 30
Figure 4-7. TCP Connection Settings _____________________________________ 32
Figure 4-8. UDP Connection Settings _____________________________________ 35
Figure 5-1. MAC Address ______________________________________________ 38
Figure 5-2. Setup Menu Options _________________________________________ 38
Figure 6-1. Network Settings ____________________________________________ 39
Figure 7-1. Serial Port Settings __________________________________________ 42
Figure 7-2. Interface Mode _____________________________________________ 43
Figure 7-3. Manual Connection Address Example ___________________________ 47
Figure 8-1. Expert Settings _____________________________________________ 56
Figure 8-2. Security Settings ____________________________________________ 58
Figure 9-1. TFTP Window ______________________________________________ 62
Figure 12-1. Serial Interface ____________________________________________ 71
Figure 12-2. DB25 Female DCE Interface RS232____________________________ 71
Figure 12-3. DB25 Female Interface RS422 (4 wire mode) ____________________ 72
Figure 12-4. DB25 Female Interface RS485 (2 wire mode) ____________________ 72
Figure 12-5. Wiring diagram for Lantronix Modem Cable, Part No. 500-163 _______ 73
Tables
Table 6-1. BootP/DHCP/AutoIP options ___________________________________ 39
Table 6-2. Standard IP Network Netmasks _________________________________ 40
Table 7-1. Interface Mode Options _______________________________________ 43
Table 7-2. Common Interface Mode Settings _______________________________ 43
Table 7-3. Flow Control Options _________________________________________ 44
Table 7-4. Reserved Port Numbers_______________________________________ 44
Table 7-5. Connect Mode Options________________________________________ 45
Table 7-6. Modem Mode Commands _____________________________________ 50
Table 7-7. Disconnect Mode Options _____________________________________ 52
Table 7-8. Flush Mode Options __________________________________________ 53
Table 7-9. Pack Control Options _________________________________________ 53
UDS1100 User Guide 6

Lantronix UDS1100 Specifications

General

Isolation	1.5 kV
Certification	UL, CSA, FCC, CE, TUV, CTick, VCC, UL 864 RoHS
Serial interface type	RS-232/422/485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	100 - 240 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
