Lantronix UDS1100 User Manual

10: Monitor Mode
Table 10-1. Monitor Mode Commands
Command Command Name Function
VS x.x.x.x Version Queries software header record (16 bytes) of unit
with IP address x.x.x.x.
GC x.x.x.x Get Configuration Gets configuration of unit with IP address x.x.x.x as
hex records (120 bytes).
SC x.x.x.x Send Configuration Sets configuration of unit with IP address x.x.x.x
from hex records.
PI x.x.x.x Ping Pings unit with IP address x.x.x.x to check device
status.
AT ARP Table Shows the unit’s ARP table entries.
TT TCP Connection
Table
Shows all incoming and outgoing TCP connections.
NC Network Connection Shows the unit’s current IP address, gateway,
subnet mask, and DNS server.
RS Reset Resets the unit’s power.
QU Quit Exits diagnostics mode.
G0, G1, ....,Ge, Gf Get configuration
from memory page
Gets a memory page of configuration information
from the device.
S0, S1,...,Se, Sf Set configuration to
memory page
Sets a memory page of configuration information
on the device.
GM Get MAC address Shows the unit's 6-byte MAC address.
SS Set Security record Sets the Security record without the encryption key
and length parameters. The entire record must still
be written, but the encryption-specific bytes do not
need to be provided (they can be null since they
are not overwritten).
SA Scan Initiates a wireless scan if the wireless interface is
enabled. Reports any stations found, including
BSSID, SSID, and RSSI. If SA is followed by a
string, the string is used to filter SSIDs before
reporting. If the BSS does not broadcast its SSID,
only the BSSID and RSSI are returned.
NS Network Status Reports the network interfaces’ statuses. Includes
potentially negotiated parameters like speed/duplex
for Ethernet or BSSID, encryption, authentication
for wireless interfaces.
co Set IP address, host
bits, gateway, and
DNS server IP
Example:
co 192.168.0.10 8 192.168.0.1 10001 192.168.1.10
with
192.168.0.10 = IP address of the UDS
8 = number of host bits
192.168.0.1 = gateway IP address
10001 = port number of the UDS
192.168.1.10 = IP address of the DNS Server
UDS1100 User Guide 65

Lantronix UDS1100 Specifications

General

Isolation	1.5 kV
Certification	UL, CSA, FCC, CE, TUV, CTick, VCC, UL 864 RoHS
Serial interface type	RS-232/422/485
Serial ports quantity	1
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
Cabling technology	10/100Base-T(X)
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	100 - 240 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
