OPTI1500D Optidrive 1500 Watt Mono Block Competition Amplifier
1 X 200w RMS At 4 Ohms •
1 X 350w RMS At 2 Ohms •
1 X 1500w Max At 0.5 Ohms •
Frequency Response: 15hz-150hz •
Input Sensitivity (Subsonic): 15hz-40hz, 24db •
Input Sensitivity (Low Level): 50hz-150hz, 24db •
Signal-To-Noise Ratio: >90db •
THD At 1watt, 4ohm: Mono Block Subwoofer •
Amplier
1 Ohm Stable •
MOSFET Power Supply •
Nickel Plated RCA Inputs •
Custom Terminal Block For Speaker Connections •
Phase Control 0-180 Degree •
Heavy Duty Power Coated Heat Sink •
Power And Protection Led Indicators •
Soft Turn-On/Turn-Off •
Dimensions: 9.40’’W X 2.32’’H X 16.93’’L•
OPTI1400D Optidrive 1300 Watt Mono Block Digital Competition Class Amplifier
500 Watts RMS Power @ 4 Ohms •
800 Watts RMS Power @ 2 Ohms •
1000 Watts RMS Power @ 1.3 Ohms •
1300 Watts Max Power @ 1.3 Ohms •
Mono Block Subwoofer Amplier •
1 Ohm Stable •
MOSFET Power Supply •
PWM (Pulse-Width-Modulated) System •
Double Sided Epoxy PCB Circuit Board •
Gold Plated RCA Inputs •
Custom Terminal Block for Speaker Connections •
Thermal, Overload Short Protection •
Remote Bass Control •
Soft Turn On/Off •
THD @ 1Watt/4 Ohm: 0.1% •
S/N Ratio: 90dB •
Frequency Response: 15Hz - 150Hz (+/-3dB) •
Damping Factor @ 20Hz/4 Ohms: 400 •
Variable Low Pass Filter: 50Hz-150Hz, •
24dB/Octave
Variable Subsonic Filter: 15Hz-40Hz, •
24dB/Octave
Variable Bass Boost: 0 to +18dB •
Phase Shift Control: 0 to 180 •
Input Sensitivity: 200mV ~ 8V •
Input Impedance: 10k Ohm •
Line Output Impedance: 100 Ohm •
Fuse Rating: 30A x 4 •
Dimensions: 10.08’’ (W) x 2.12’’ (H) x 14.96’’ (L)•
OPTI1900D Optidrive 1900 Watt Mono Block Competition Amplifier
1 X 500w RMS At 4 Ohms •
1 X 800w RMS At 2 Ohms •
1 X 1900w Max At 1.3 Ohms •
Frequency Response: 15hz-150hz •
Input Sensitivity (Subsonic): 15hz-40hz, 24db •
Input Sensitivity (Low Level): 50hz-150hz, 24db •
Signal-To-Noise Ratio: >90db •
THD At 1watt, 4ohm: Mono Block •
Subwoofer Amplier
1 Ohm Stable •
MOSFET Power Supply •
Nickel Plated RCA Inputs •
Custom Terminal Block For Speaker Connections •
Phase Control 0-180 Degree •
Heavy Duty Power Coated Heat Sink •
Power And Protection Led Indicators •
Soft Turn-On/Turn-Off •
Dimensions: 9.40’’W X 2.32’’H X 21.22’’L•
OPTI2000D Optidrive 2000 Watt Half Ohm Stable Mono Block Digital Competition Class
Amplifier
700 Watts RMS Power @ 4 Ohms •
1100 Watts RMS Power @ 2 Ohms •
1600 Watts RMS Power @ 1.3 Ohms •
2000 Watts Max Power @ 0.5 Ohms •
4000 Watts Bridge Max Power @ 2 Ohms •
Mono Block Subwoofer Amplier •
0.5 Ohm Stable •
MOSFET Power Supply •
PWM (Pulse-Width-Modulated) System •
Double Sided Epoxy PCB Circuit Board •
Gold Plated RCA Inputs •
Custom Terminal Block for Speaker Connections •
Thermal, Overload Short Protection •
Remote Bass Control •
Soft Turn On/Off •
THD @ 1Watt/4 Ohm: 0.1% •
S/N Ratio: 90dB •
Frequency Response: 15Hz - 150Hz (+/-3dB) •
Damping Factor @ 20Hz/4 Ohms: 400 •
Low Pass Filter: 50Hz-150Hz, 24dB/Octave •
Variable Subsonic Filter: 15Hz-40Hz, •
24dB/Octave
Variable Bass Boost: 0 to 18dB •
Variable Phase Control: 0 to 180 •
Input Sensitivity: 200mV ~ 8V •
Input Impedance: 10k Ohm •
Line Output Impedance: 100 Ohm •
Fuse Rating: 30A x 6 •
Dimensions: 10.08’’ (W) x 2.12’’ (H) x 19.1’’ (L)•
OPTI3500D 3500 WATT Mono Block MOSFET Digital Power Amplifier
3500 Watt Mono Block Subwoofer Amplier•
1800 Watts RMS @ 4 Ohms•
2000 Watts RMS @ 2 Ohms•
2500 Watts RMS @ 1 Ohms•
3500 Watts RMS @ 0.5 Ohms•
0.5 Ohm Stable•
MOSFET Power Supply•
PWM (Pulse-Width-Modulated) System•
Double Sided Epoxy PCB Circuit Board•
Nickel Plated RCA Inputs•
Custom Terminal Block for Speaker Connections•
Thermal, Overload & Short Protection •
Variable Low Pass Filter •
(50Hz-250Hz-24dB/Octave)
Variable Subsonic Filter •
(15Hz-40Hz-24dB/Octave)
Phase Control 0-180 degree•
THD @ 1 Watt, 4 Ohm: 0.1%•
Signal To Noise Ratio: 90dB•
Input Sensitivity: 200mV-8V•
Remote Bass Control•
Input Impedance: 10K Ohms•
Soft Turn On/Off•
Heavy Duty Power Coated heatsink•
Dimesnions: 10.08’’W x 2.12’’H x 23.3’’L•
optidrive series amplifiers
