Description
1 Current Play mode
2 Current Repeat Mode
3 Track number of total in
folder/List
4 Current Bit Rate
5 Time
6 Current EQ setting
7 Battery Status Icon
8 Track Name
9 Artist Name
10 Album Name
11 Status Bar
12 Current time code
13 Play/Pause
14 Total time of track
15 Current Volume Settings
16 Lyrics for Current track*
*A separate Lyric (.LRC) file must be in the same
folder as the music file to be displayed. Music
file and Lyric file must have the same name.
EG: MUSIC_FILE.MP3 must be accompanied by
the file MUSIC_FILE.LRC for the lyrics to be
displayed.
3.3 Music Playback Options
The following buttons can be used during music playback.
Button Action
Left Go to previous audio track
Right Go to next audio tack
Return Go back to previous screen
Play / Pause Press to play/pause current audio track.
Up Increase volume
Down Decrease volume
Enter Press to display playback options See below
