22
through the process of “Select lens” (refer to page 23). After changing the lens,
press AUTO FOCUS key to save the new focal length in memory. LCD will show
as follows:
NOTE:
1. “0.0 mm” means the focus position is the Z-axis home position of the
Working table. Above this position the value is negative while below
this position the value is positive.
2.Whenever the motion system or working table has ever been adjusted
by
a technical person, please press AUTO FOCUS key to get an initial
position before going through the function of “Tune (Auto focusing)” to
change the focal length.
Arrow Keys
Move cursor on the display for selection or adjust the working table on Z position by
pressing the arrow keys of UP and DOWN.
NOTE:
UP key – After initializing, press this key will move up the table. LCD
displays:
During working time (i.e. Start condition), this message won’t be shown.
When Auto Focus is under process, press UP key will stop the motion of
Auto Focus and change to up movement.
DOWN key – Same as above function but the motion direction is
opposite.
Focusing
Then do setup or send a file
to start a job
0.0 mm
Focusing
Then do setup or send a file
to start a job
X.X mm
NOTICE:
To stop the motion of auto focus, please press either UP or DOWN arrow
key. If you press the key continuously, working table will move up or down
correspondingly.
