Laspaziale S8 DSP - Page 38

36
LSI 090 - Rev. 00 - Ed. 04/2018
EXPANSION BOARD COD. 8893
The M.A.T. Board code 8893 is compatible with the machines Series S40 Classic_
Suprema and S8/S9 DSP depending on the con guration of the contact MC1:
M.A.T. OFF
M.A.T. ON
Fig. 31
Fig. 32
S40CLASSIC_SUPREMA-S8/S9DSP
SCHEDAESPANSIONECOD.8893–EXPANSIONCONTROLBOARDPARTNO.8893
S40CLASSIC_SUPREMA-S8/S9DSP
SCHEDAESPANSIONECOD.8893–EXPANSIONCONTROLBOARDPARTNO.8893
S40CLASSIC_SUPREMA-S8/S9DSP
SCHEDAESPANSIONECOD.8893–EXPANSIONCONTROLBOARDPARTNO.8893
