Laspaziale S8 DSP - General Description of the Push-Button Keyboard

7
LSI 090 - Rev. 00 - Ed. 04/2018
LEGEND OF EK VERSION:
5-KEY BOARD FOR COFFEE
DELIVERY
A. 1 short coffee key.
B. 1 long coffee key.
C. Continuous delivery key.
D. 2 short coffees key.
E. 2 long coffees key.
LEGEND OF EP VERSION:
KEY FOR COFFEE DELIVERY
F. Manual coffee delivery key.
Fig. 6
1.2 GENERAL DESCRIPTION OF THE PUSH-BUTTON KEYBOARD
A B C D E F
