Laspaziale S8 DSP - Technical Data

47
LSI 090 - Rev. 00 - Ed. 04/2018
9. TECHNICAL DATA
H
L P
Fig. 33
DIMENSIONS AND WEIGHT
S8 DSP • S9 DSP 2 GR 3 GR 4 GR
L 770 1000 1235
H 520 520 520
P 530 530 530
WEIGHT KG 65 80 97
POWER SUPPLY RATING AND ABSORPTION
S8 DSP • S9 DSP 2 GR 3 GR 4 GR
VOLT 400/220-240 400/220-240 400
Hz 50/60 50/60 50/60
W 3300 4300 6300
W+ 3800 6300 (400V) -
