41
LSI 090 - Rev. 00 - Ed. 04/2018
LEGEND:
G = Ground
N = Neutral
L1 = Line 1 phase
L2 = Line 2 phase
L3 = Line 3 phase
IG = Main switch
RS1 = Static relay 1
RS2 = Static relay 2
TS = Safety thermostat
RC = Boiler heating element
F = Electric board
VR = Varistor
