43
LSI 090 - Rev. 00 - Ed. 04/2018
LEGEND:
T = Transformer 230/10 Vac 1A
A = Switching feeder
100/240Vac-24Vcc 0,5A 50/60Hz
BL = Led bar for cups lighting
MP = Pump motor
RS = Cup warmer heating element
F1 = Fuse
SL = Boiler level probe
S1 = Boiler temperature probe PT1000
DL8 = Hot water delivery button led
P5 = Hot water delivery button
R = Reed
P1 = Touchpad, 1st group from the right
P2 = Touchpad, 2nd group from the right
P3 = Touchpad, 3rd group from the right
P4 = Touchpad, 4th group from the right
F1 = Flow meter for 1st group from the right
F2 = Flow meter for 2nd group from the right
F3 = Flow meter for 3rd group from the right
F4 = Flow meter for 4th group from the right
PP = Programming push-button
EV1 = Coffee delivery solenoid valve for 1st group from the right
EV2 = Coffee delivery solenoid valve for 2nd group from the right
EV3 = Coffee delivery solenoid valve for 3rd group from the right
EV4 = Coffee delivery solenoid valve for 4th group from the right
EVA = Automatic level solenoid valve
EVH = Hot water delivery solenoid valve
EV AM = Water mixing solenoid valve
DL0 = Pilot light ON/OFF
DL1 = Pilot light for cup warmer heating element
DL2 = Pilot light for M.A.T. system
DL3 = Pilot light for thermoregulation
DL4 = Pilot light for G.A. technical service
DL5 = Pilot light for boiler temperature probe
DL6 = Pilot light for automatic level
DL7 = Pilot light for ECO function.
