Proline Low-temperature Thermostats
YACE0072 / 21.08.07 Controls and functional elements 13
Mobile Command Console (see next page)
Covers for the two module slots
Connection socket 10S
for the external Pt1
tem
erature
robe
Connection socket 70S (LAUDA internal bus
(LiBus)) for bus suitable for unit and to which
the refrigerating lower section, the integrated
electricall
heated cover
late and Command
Main fuse-switch
Connection socket 51H for refrigerating lower
section
Mains connecting lead
Air intake for electronic head
Rear pump connection:
Suction nozzle (return to bath)
Rear pump connection:
Pump outflow, pressure output
Transport handle
Rear grid
Bypass valve
(in "external" position)
Side pump connection:
Pump outflow, pressure output
(closed off with screw plug)
Side pump connection:
Suction nozzle (return to bath)
(closed off with screw plug)
