12 Controls and functional elements YACE0072 / 21.08.07
3 Controls and functional elements
Mobile Command Console
(
see
p
a
g
e 14
)
Master control panel (see page 14)
Mains switch
Pump connection at side:
Suct
i
o
n n
o
zzl
e
(
r
etu
rn
to
bat
h
)
Bypass valve (see illustration on next page)
Side pump connection:
Pump outflow, pressure output
Bath cover
Recessed grip
Grille (on both sides)
Front cover (closed)
Transport rollers (concealed)
Feet (concealed)
Front cover (open)
Bath drain tap
Bath drain nozzle
Condenser
