LAUNCH Creader V+ User’s Manual
8
3 LCD DISPLAY
Indicates test results.
4 EXIT BUTTON
Returns to previous menu.
5 UP BUTTON
Move cursor up for selection.
6 ENTER BUTTON
Confirms a selection (or action) from a
menu list.
7 RIGHT BUTTON
Move cursor right for selection; Or turn
page down when more than one page is
displayed.
8 DOWN BUTTON
Move cursor down for selection.
9 LEFT BUTTON
Move cursor left for selection; Or turn
page up when more than one page is
displayed.
10 USB PORT
Connects to computer to update the
Creader V+ online.
3.2 Specifications
1) Screen: 2.4” TFT, 176*220 dots LCD display
2) Input voltage range: 9 ~ 18V
3) Operating temperature: 32°F~122°F / 0°C~50°C
4) Storage tempetature: -4°F~158°F / -20°C ~70°C @ RH60%
5) Outline dimension: 120*75*20 mm (L x W x H)
6) Weight : <17.6 oz (500g)
3.3 Accessories
1) User’s Manual -- Instructions on tool operations
2) USB cable -- Connect to a computer for upgrading online
3.4 Power supply
The power of the Creader V+ is provided via the vehicle Data Link Connector
(DLC). Follow the steps below to power it up:
1) Find DLC on vehicle
A plastic DLC cover may be found for some vehicles and you need to
remove it before plugging the OBDII cable.
2) Plug the connector at the end of OBD II cable to the vehicle’s DLC.
