LAUNCH Creader V+ User’s Manual
11
4. Operations
4.1 Connection
1) Turn the ignition off.
2) Locate the vehicle’s 16-pin Data Link Connector (DLC).
3) Plug the OBDII cable into the vehicle’s DLC.
4) Turn the ignition on. Engine can be off or running.
5) After finishing, press [ ] button to enter Main Menu as following figure 4-1:
Figure 4-1
CAUTION: Don’t connect or disconnect any test equipment with ignition on
or engine running.
4.2 Diagnose
Select [Diagnostic] in Main Menu and press [ ], the screen will display Monitor
Status interface as following figure 4-2:
Figure 4-2
