TLT235、TLT240 Economical Two-post User’s Manual
36
108
103040157
Seal gasket14
109 103260129 Sub cylinder
110 103220054 Sheave seat
111 104060016 Returning ring 32
112
103050014 Returning ring 30
113 103201950 Sheave
114
103200973 Sheave axle
115
103200939 Leaf chain
116 X103060340 Pin 2×26
117
103200938
Chain threaded end
118
103030131
Nut M16
119
103100198
Fitting
120
104120118 Offside column HP Hose
121 103020166 Connecting bolt
122
103260098 Bushing3052
123
103990278
JY Cylinder seal kit
201
103202373 TLT235SC /TLT235SC(U)carriage
103202695 TLT240SC carriage
103202696 TLT240SB carriage
103202277 TLT235SB carriage
202
104990132 Sliding block
103202958
Sliding block adjustment shim（for adjusting）
203
104130186
Rubber pad on swing arm
204
103010608
Screw M6×10
205 103202032 Semi-gear
206 104130191 Door rubber pad
207 103010539 ScrewM8×12
208 103011102 ScrewM10×25
209
103202184 Top rod assembly
210 103202280 Pin
211
103202278
Swing arm
212
103201914
Spring
213
103201744
Gear block
214 103060376 Pin 5×32
215 103050030 Returning ring 40
216 103060355 Pin 3.2×30
217
103201444
Lifting pad assembly
218
104130189 Rubber pad
219
103202765
TLT235SB /TLT235SC /TLT235SC(U) top board
103202766
TLT240SB/ TLT240SC top board
220
103020215
ScrewM10×25
221
103020093
Screw M8×16
222
103200962
Steel cable
