TLT235、TLT240 Economical Two-post User’s Manual
37
223
103030131
Nut M16
224 103040159 Spring washer16
225
103040136
Flat washer16
226 103110061 Spring
227
103202345
Safety block
228 103010471 ScrewM8×40
229 103110060 Spring
301
201021653 TLT235SBPower side column
201024751 TLT240SBPower side column
302
201021652
TLT235SBOffside column
201024750
TLT240SBOffside column
303
103202810
TLT235SB Bracket 0f power unit
103202906
TLT240SB Bracket 0f power unit
304
103010326 Screw M6×12
307
201025072
Floor plate
308 201025071 Floor plate cover
309
201021655 TLT235SB Top plate assembly
201024764 TLT240SB Top plate assembly
311
103203017 Top pulley
312
103200699 Bushing 2520
313
103050031 Retaining ring 25
314
103040176 Washer
317
103040110 Flat washer 12
318
103040044 Spring washer 12
319
103020104 Bolt M12×35
320
103040123 Flat washer 10
321 103040122 Spring washer 10
322
103020038 Bolt M10×25
323
1103260337
Steel cable
324
103020123 Anchor bolt M18×160
103020117 Anchor bolt M19×140
325 103201071 Cover of hose
326 103010432 Screw M5X12
327 103040132 Washer5
401
Power unit
402
103202194 Fitting
403
104120076 HP Hose
404 103100324 Throttle joint
405
103040157
Seal gasket14
406
103260098
Bushing3052
407 104120079 HP Hose
