Launch TLT235SC - Page 44

TLT235、TLT240 Economical Two-post User’s Manual
38
408
103260123
Master cylinder
409 103260129 Sub cylinder
410 103220126 Sheave seat
411
103050029
Returning ring 32
412
103050020 Returning ring 30
413 103201950 Sheave
414
103201883 Sheave axle
415
103200939
Leaf chain
416 X103060340 Pin 2×26
417
103200938
Chain threaded end
418
103030131
Nut M16
419
103990278
JY Cylinder seal kit
501
201025100 TLT235SC Power side column
201025104 TLT240SC Power side column
502
201025101
TLT235SC Offside column
201025105
TLT240SC Offside column
503
201024770 TLT235SC Extension column
201025112 TLT240SC Extension column
504
103202858 Protective cover inside the column
505
201011152
Protective cover for extension column
506
103201070 Bottom cover of column
507 103010498 ScrewM5×8
508 103040132 Flat washer5
509
103202811
Connecting bracketⅠ
510 103020104 Bolt M12×35
511 103040110 Flat washer12
512 103040044 Spring washer12
513
103202812
Connecting bracketⅡ
514 103040123 Flat washer10
515 103040122 Spring washer10
516 103020038 Bolt M10×25
517
201011176 Reinforced plate
518
103010429
ScrewM4×25
519 103201545 Bracket
520
105990008 Limit switch
521
103202817 Inner top beam
522 103202818 Outer top beam
523
103020123 Anchor bolt M18×160
103020117 Anchor bolt M19×140
524
103060342
Pin 3X26
525 103250270 Long rod
526
103203197
Long rod axle
527 103203325
BushingⅡ
