CS2RS Series Modbus RS485 Closed Loop Stepper Drive User Manual
RS485 data type selection
0: 8-bit data, even check, 2 stop bits;
1: 8-bit data, odd check, 2 stop bits
2: 8-bit data, even check, 1 stop bit;
3: 8-bit data, odd check, 1 stop bit:
4: 8-bit data, no check,1 stop bit:
5: 8-bit data, no check,2 stop bits;
This JOG is triggered by RS485.
For JOG triggered by IO, please use Pr8.40/8.41
Encoder resolution of closed-loop stepper motor
Current loop proportional
KP
It is recommended to keep the factory value,
when disable auto-tuning, can be modified
Save all parameters to
EEPROM
Parameter reset(exclude
motor parameters)
All parameters are reset to
factory
Save all mappings into
EEPROM
JOG CW (Need to write
once at least 50ms)
JOG CCW (Need to write
once at least 50ms)
Save parameter status
word
