USER’S MANUAL
OBDII Auto Scanner
10
3.2 Specifications
Screen: 2.8" TFT color screen.
Input voltage range: 8~32V
Operating temperature: 32_~122 C
Storage temperature: -4 ~158_ / -20 ~70 C
Outline dimension: 20*8.5*2.8CM
Weight : <17.6 oz (500g)
3.3 Accessories Included
User Manual -- Show the user how to operate the tool.
CD -- Include the software.
USB cable -- Connect to a computer for upgrading online.
3.4 Power supply
The power of the Car scanner is provided via the vehicle Data Link
Connector (DLC). Follow the steps below to power it up:
A. Find DLC on vehicle: A plastic DLC cover may be found for some
vehicles and you need to remove it before plugging the OBDII cable.
B. Plug the connector at the end of OBD II cable to the vehicle.
3.1 Tool Description
1. LCD DISPLAY -- Indicates test information.
2. ENTER BUTTON--Confirms a selection (or action) from a menu.
3. ESC BUTTON -- Returns to previous menu.
4/5. RIGHT/LEFT BUTTONs -- Move cursor right or left for selection; Or
turn page up or down when more than one page is displayed.
6/7. UP/DOWN BUTTONs-- Move cursor up or down for selection.
8.POWER SWITCH -- Turns on/off the scan tool when powered by cell
battery; resets the scanner when powered by vehicle battery.
9. OBD II CONNECTOR -- Connects the AUTO SCANNER to the vehicle.
To Next Page
