USER’S MANUAL
OBDII Auto Scanner
22
con.
Sel ect O2 Sensor
Bank1-Sensor1
Bank1-Sensor2
Select [O2 Sensor Test] in Diagnostic menu and press [ENTER] and the
screen will display as shown below
4.2.6 O2 sensor test
The results of O2 sensor test are not live values but instead the results of
the ECU live sensor screens such as Graph Screen.
Not all test values are applicable to all vehicles. Therefore, the list
generated will vary depending on vehicle. In addition, not all vehicles
support the Oxygen Sensors screen.
You can use [LEFT] [RIGHT] button to view the data.
Press [ESC] to return to Diagnostic Menu.
con.
F reeze Frame
DTC that caused required
freeze frame data storage
B3376
Short term fuel trim - bank 1 16.4%
Short term fuel trim - bank 3 71.1%
Long term fuel trim - bank 1 0.0%
Long term fuel trim - bank 3 64.1%
1/5
To Next Page
