USER’S MANUAL
OBDII Auto Scanner
13
4. OPERATION
4.1 Connection
1). Turn the ignition off.
2). Locate the vehicle
3). Plug the OBDII cable into the vehicle
4). Turn the ignition on. Engine can be off or running.
After finishing, press [ENTER] button to enter Main Menu as following
picture:
3.6 Vehicle Coverage
This model OBDII/EOBD Scanner is specially designed to work with all
OBD II compliant vehicles, including those equipped with next-generation
protocol -- Control Area Network (CAN). It is required by EPA that all 1996
and newer vehicles (cars and light trucks) sold in the world must be OBD
II compliant and this includes all America, Asian and European vehicles.
A small number of 1994 and 1995 model year gasoline vehicles are
OBD II compliant. To verify if a 1994 or 1995 vehicle is OBD II compliant,
check the Vehicle Emissions Control Information (VECI) Label which is
located under the hood or by the radiator of most vehicles. If the vehicle is
OBD II compliant, the label will designate "OBDII Certified". Additionally,
Government regulations mandate that all OBDII compliant vehicles must
have a "common" sixteen-pin Data Link Connector (DLC).
For your vehicle to be OBD II compliant it must have a 16-pin DLC
(Data Link Connector) under the dash and the Vehicle Emission Control
Information Label must state that the vehicle is OBD II compliant.
OBDII 16 pin, BMW series 1-8, I/X/Z, Mini after 2000, all 150 systems,
including Engine, A/T, ABS, ACC, ARS, SRS, EML, A/C, Baterry, BFS,
BZM, CA,CAS, CEM, etc.
Press [UP] or [DOWN] to select ON/OFF and press [ENTER] to confirm.
When this function is ON, and the icon record Datastream and record
Freeze Frames.
